KIT JOPIX PT-31 + ANTENNA SUPER SANTIAGO 200 (34 cm)

KIT JOPIX PT-31 + ANTENNA SUPER SANTIAGO 200 (34 cm) - Pedro Nevada

EAN Jopix PT-31: 8435550803498

EAN Super Santiago 200: 8435550803986

Price: 79.00 € (VAT included)

Prices can be changed with no previously communication.



CB RADIO JOPIX PT-31



The Jopix PT-31 is a multi-standard CB radio (Band 27 MHz, license-free) with AM and FM, it has a multi-function LCD screen with S-meterscanner, channel up/down from microphone, manual and automatic squelch. The "SMT" technology that incorporates the Jopix PT-31, in addition to providing a reduced size, guarantees the best stability, reliability and quality.



Features and technical specifications:

- LCD screen. Backlit display with channel indicator and equipment functions.

- Channel search

- Reduced size

- Handheld microphone, detachable on the side

- [UP] / [DOWN] keys on the handheld microphone

- Microphone gain

- Microphone gain adjustment

- Microphone with detachable RJ-45 plug

- Jack for external speaker

- Automatic "ASQ" squelch adjustment (9 levels)

- Emergency channel

- Keypad lock

- Removable stand included

- 40 channels

- Frequencies: from 26.965 to 27.405 MHz

- Modes: AM/FM

- RF output power: 4 W

- Antenna impedance: 50 Ω

- Antenna plug: SO-239

- Power: 13.8 V DC (nominal)

- Operating temperature: -20ºC to +60ºC

- Duty cycle: 5 - 5 - 90% (TX - RX - Standby)

- Size: 120 x 110 x 27 mm

- Weight: 424 g



ANTENNA SUPER SANTIAGO 200 (34 cm)



Specifications:

- CB mobile antenna with magnetic base

- Frequency: 26 to 28 MHz

- Gain: 3 dB

- Polarization: vertical

- Impedance: 50 Ω

- Maximum power: 50 W

- Materials: steel + ABS + copper

- Ø magnetic base: 7 cm

- Antenna supplied with 4 m of RG-58 cable and PL plug

- Size: 31.7 x 34 cm

- Weight: 400 g
